0MAX MODULE EFFICIENCY : 22.5%
POWER TOLERANCE : 0~ 3%
FIRST YEAR POWER DEGRADATION : <2%
High module conversion efficiency
Reduced resistive loss with lower operating current
Higher energy yield with lower operating temperature
Reduced hot spot risk with optimized electrical design and lower operating current
Max Module Efficiency
Power Tolerance
First Year Power Degradation
Year 2-25 Power Degradation
| Mechanical Parameters | |
| Cell Orientation | 108 (6×18) |
| Junction Box | IP68, three diodes |
| Output Cable | 4mm², 300mm in length, length can be customized |
| Glass | Dual glass, 2.0+1.6mm semi-tempered glass |
| Frame | Anodized aluminum alloy frame |
| Weight | 23.6kg |
| Dimension | 1800×1134×30mm |
| Packaging | 36pcs per pallet / 216pcs per 20’GP / 846pcs per 40’HC |
Mainly distributed in countries and regions:Germany, Spain, Italy, Tunisia, France, Netherlands, United Kingdom, Austria, Switzerland, Czech Republic, Sweden, Australia, New ZealandSouth Africa, United Arab Emirates, Argentina, Brazil, Colombia, Canada, Malaysia, Singapore, Thailand, Vietnam, Japan
